Budget Carbon Filters with pre-filter material sleeves, now available in the following sizes:
100 mm ⌀ (flange diameter): Length: 500 mm. Capacity: 300 m3/hr. Weight: 5.o5 kg
150 mm ⌀ (flange diameter): Length: 600 mm. Capacity: 500 m3/hr. Weight: 7.2 kg
200 mm ⌀ (flange diameter): Length: 600 mm. Capacity: 850 m3/hr. Weight: 9.8 kg
Filters normally last between 12 and 18 months before full adsorption, depending on air quality filtered and hours used per day. Carbon filters stop working in 85% + R.H. environments, do not use in super humid environments.
Don’t forget to add a set of Garden HighPro ProHangers to your order, to hang your carbon filter with, if needed.
More on air filtering with carbon scrubbers/filters…
Matching an extraction fan with a carbon air filter for a grow room is essential for maintaining optimal air quality and controlling odors effectively. To achieve the best results, the airflow capacity of the extraction fan, measured in cubic meters per hour (m³/h), should be compatible with the carbon filter’s rated m³/h. This ensures that the fan can effectively pull air through the filter without overwhelming it. Additionally, considering the size of the grow room is crucial; the fan and filter combination should be capable of exchanging the air in the room every 1-3 minutes. For instance, a grow room with a volume of 6 cubic meters would require an extraction system with a capacity of 120-360 m³/h. Properly matching these components not only maximizes odor control but also maintains a healthy environment by efficiently removing excess heat and humidity, crucial for the successful cultivation of plants like cannabis.
When adding a carbon filter (like the Budget Carbon Filters) to an extraction fan system, it’s important to account for the inevitable capacity loss that occurs due to the added resistance. A carbon filter can reduce the fan’s effective airflow by up to 25-30%, depending on the filter’s quality and the density of the carbon. This reduction means that if your fan is rated for 300 m³/h, the actual airflow might drop to around 210-225 m³/h once the filter is installed. To compensate for this loss, it’s advisable to choose a fan with a higher capacity than initially required or ensure that the combined system’s capacity still meets the necessary air exchange rates for your grow room. Properly accounting for this capacity loss ensures efficient air purification and maintains the desired environmental conditions for optimal plant growth.
ProActiv Carbon Filters use only 100% food grade virgin coconut activated carbon, encased in multi-layer fleece mats that are sealed air-tight on both ends of the scrubber.
Installation is super easy – just clip each end of the filter onto a rope ratchet and attach your ducting!
Get rid of unwanted odours by attaching a carbon filter before your exhaust fan/s.
In a closed-system grow area, cycle your air through a carbon filter to help keep it free from dust, mold spores and bacteria. (Be sure to DEHUMIDIFY – carbon filters stop working in 85% + R.H. environments !)
Clean and scrub your incoming air supply and stop pests like spider mites and others from getting into your grow area by installing a carbon filter before your inlet fan/s.
How match your Garden HighPro ProActiv Carbon Filters up with the correct sized inline fans:
1) First, determine how much air-flow your will need through your grow space. If you are using fans to exhaust heat caused by hot HPS grow-lamps, a quick calculation can be done…
Number of lamps × Watts of each lamp ÷ 2 = Required cubic meters per hour of air flow needed.
(We recommend adding × 1.2 to this answer for our HOT ZA summers!)
2) Find one or more fans (whichever will best suit your area) that will provide a total airflow =/> than what has been worked out in step 1.
3) Match up each of your chosen fans with a carbon filter of the same diameter (preferably, to avoid the additional cost of ducting reducers). Also check the filter length if installing in cramped spaces.
VERY IMPORTANT: ALSO make sure that the filter’s air-flow capacity matches or exceeds the fan’s airflow rating, using the ProActive Filter table below. If too much air passes through the filter, it will not be able to scrub the passing air thoroughly!
4) Once your fans and filters have been matched up, it’s time to work out how many meters of ducting your will need, as well as other accessories, like Rope Ratchets, Ducting Clamps, or rolls of Aluminium Tape.
The CAN-Lite 425 PL Carbon Filter weighs in at only 2.2 kg, making it easy to hang from rope ratchets. With a length of 60 cm, this little filter can be used in small to medium grow spaces. Filled to the brim with 1.6 kg of activated carbon using vibration plates during manufacture, your air will be filtered to perfection. The removable pre-filter can be hand-rinsed when necessary and the filter is also refillable.
The filter is able to purify up to 425 m3/hr. ( It can be matched up with a fan with a maximum capacity of 467 m3/hr, as there is generally an air-flow loss of around 20% when a filter is added into the extraction setup. )
PLEASE NOTE: The CAN-Lite 425 PL Carbon Filter can be fitted with either a 100mm OR a 125mm Flange ( SOLD SEPARATELY! ) … don’t forget to add a flange to your cart with your purchase !
Carbon Filters will not work in spaces with a Relative Humidity of 85% or higher.
The CAN-Lite 300 PL Carbon Filter weighs in at only 1.8 kg, making it very easy to hang from rope ratchets. With a length of 45 cm, this little filter can be used in smaller grow spaces. Filled to the brim with 1.2 kg of activated carbon using vibration plates during manufacture, your air will be filtered to perfection. The removable pre-filter can be hand-rinsed when necessary and the filter is also refillable.
The filter is able to purify up to 300 m3/hr. ( It can be matched up with a fan with a maximum capacity of 330 m3/hr, as there is generally an air-flow loss of around 20% when a filter is added into the extraction setup. )
PLEASE NOTE: The CAN-Lite 300 PL Carbon Filter can be fitted with either a 100mm OR a 125mm Flange ( SOLD SEPARATELY! ) … don’t forget to add a flange to your cart with your purchase !
Carbon Filters will not work in spaces with a Relative Humidity of 85% or higher.
The CAN-Lite 150 PL Carbon Filter weighs in at only 1.2 kg, making it incredibly easy to hang from rope ratchets. With a length of only 25 cm, this little filter can also be squeezed into the tiniest of grow spaces. Filled to the brim with 700 g of activated carbon using vibration plates during manufacture, your air will be filtered to perfection. The removable pre-filter can be hand-rinsed when necessary and the filter is also refillable.
The filter is able to purify up to 150 m3/hr. ( It can be matched up with a fan with a maximum capacity of 165 m3/hr, as there is generally an air-flow loss of around 20% when a filter is added into the extraction setup. )
PLEASE NOTE: The CAN-Lite 150 PL Carbon Filter can be fitted with either a 100mm OR a 125mm Flange ( SOLD SEPARATELY! ) … don’t forget to add a flange to your cart with your purchase !
Carbon Filters will not work in spaces with a Relative Humidity of 85% or higher.
The Can-Lite PL Range Carbon Filter Flange twists onto the lightweight Can-Lite PL Plastic Carbon Filter range (Filters sold separately). The Can-Lite PL range allows for the flange to twist off for easy maintenance or replacement of the Can-Lite PL Carbon Filters.
PLEASE NOTE:
There is a slight incompatibly when using these flanges with local ducting supplies – the exact flange measurements are as follows:
“100 mm” Flange: Inner diameter = 100 mm, outer diameter = 106 mm – Although a tight fit, our local 100 mm ducting fits over the flange reasonably easily.
“125 mm” Flange: Inner diameter = 125 mm, outer diameter = 130 mm – This outer diameter is just a bit too large to fit 125 mm ducting over ( We recommend using Aluminium Tape or Duct Tape to connect the ducting to this flange size, instead of trying to get the ducting to fit over the flange and then using a clamp to secure the ducting )
AC Infinity 8 Inch Carbon Air Filter PRODUCT DESCRIPTION
A high-airflow duct filter designed to eliminate odors and chemicals, utilizing a premium-grade Australian Virgin charcoal bed. This activated carbon bed has RC412 pore sizes that enable a high adsorption rate and longer life rating. Its heavy-duty construction features aluminum flanges and dual-sided galvanized steel mesh with a rust-resistant gunmetal finish to stand up to corrosion and high humidity. The carbon filter can be used with an inline duct fan for use in intake and exhaust configurations, while its flanges can be reversed to further prolong its lifespan. Includes two machine-washable pre-filter cloths to prevent carbon residue, plus two rope clip hangers and two hanging straps for easy installation.
PREMIUM GRADE CARBON
Each carbon filter features premium-grade Australian Virgin carbon rated at 1200+ IAV. It comprises a 38 mm charcoal bed thickness that has a higher microporosity and helps achieve a greater surface area rating. This, when combined with its wide mesh opening, not only enables a greater adsorption rate without restricting free airflow but also extends its lifespan by up to 33%. Most used in hydroponics systems, grow tents, grow rooms, kitchens, smoking areas, and other ventilation projects.
Product Identification
Manufacturer
AC Infinity Inc.
Product Name
Duct Carbon Filter 8″
Product Model
AC-DCF8
UPC Code
819137020689
Product and Mounting Dimensions
Duct Opening Size
8″
Total Dimensions
18.11 x 10.90 in. (46.0 x 27.7 cm)
Flange Length
3.39 in. (8.6 cm)
Product Performance and Technical Specs
Flange Material
Aluminum
Flange Design
Reversible
Mesh Material
Rust-Resistant Galvanized Steel with Gunmetal Finish
AC Infinity 6 Inch Carbon Air Filter PRODUCT DESCRIPTION
A high-airflow duct filter designed to eliminate odors and chemicals, utilizing a premium-grade Australian Virgin charcoal bed. This activated carbon bed has RC412 pore sizes that enable a high adsorption rate and longer life rating. Its heavy-duty construction features aluminum flanges and dual-sided galvanized steel mesh with a rust-resistant gunmetal finish to stand up to corrosion and high humidity. The carbon filter can be used with an inline duct fan for use in intake and exhaust configurations, while its flanges can be reversed to further prolong its lifespan. Includes two machine-washable pre-filter cloths to prevent carbon residue, plus two rope clip hangers and two hanging straps for easy installation.
PREMIUM GRADE CARBON
Each carbon filter features premium-grade Australian Virgin carbon rated at 1200+ IAV. It comprises a 38 mm charcoal bed thickness that has a higher microporosity and helps achieve a greater surface area rating. This, when combined with its wide mesh opening, not only enables a greater adsorption rate without restricting free airflow but also extends its lifespan by up to 33%. Most used in hydroponics systems, grow tents, grow rooms, kitchens, smoking areas, and other ventilation projects.
Product Identification
Manufacturer
AC Infinity Inc.
Product Name
Duct Carbon Filter 6″
Product Model
AC-DCF6
UPC Code
819137020672
Product and Mounting Dimensions
Duct Opening Size
6″
Total Dimensions
15.74 x 8.93 in. (40.0 x 22.7 cm)
Flange Length
1.57 in. (4.0 cm)
Product Performance and Technical Specs
Flange Material
Aluminum
Flange Design
Reversible
Mesh Material
Rust-Resistant Galvanized Steel with Gunmetal Finish
AC Infinity 4 Inch Carbon Air Filter PRODUCT DESCRIPTION
A high-airflow duct filter designed to eliminate odors and chemicals, utilizing a premium-grade Australian Virgin charcoal bed. This activated carbon bed has RC412 pore sizes that enable a high adsorption rate and longer life rating. Its heavy-duty construction features aluminum flanges and dual-sided galvanized steel mesh with a rust-resistant gunmetal finish to stand up to corrosion and high humidity. The carbon filter can be used with an inline duct fan for use in intake and exhaust configurations, while its flanges can be reversed to further prolong its lifespan. Includes two machine-washable pre-filter cloths to prevent carbon residue, plus two rope clip hangers and two hanging straps for easy installation.
PREMIUM GRADE CARBON
Each carbon filter features premium-grade Australian Virgin carbon rated at 1200+ IAV. It comprises a 38 mm charcoal bed thickness that has a higher microporosity and helps achieve a greater surface area rating. This, when combined with its wide mesh opening, not only enables a greater adsorption rate without restricting free airflow but also extends its lifespan by up to 33%. Most used in hydroponics systems, grow tents, grow rooms, kitchens, smoking areas, and other ventilation projects.
Product Identification
Manufacturer
AC Infinity Inc.
Product Name
Duct Carbon Filter 4″
Product Model
AC-DCF4
UPC Code
819137020665
Product and Mounting Dimensions
Duct Opening Size
4″
Total Dimensions
11.81 x 6.96 in. (30.0 x 17.7 cm)
Flange Length
1.46 in. (3.7 cm)
Product Performance and Technical Specs
Flange Material
Aluminum
Flange Design
Reversible
Mesh Material
Rust-Resistant Galvanized Steel with Gunmetal Finish
RAM AirTech Heavy Filter 250mm: 250mm diameter, 2000M³/H – a high-quality long life air filter using premium Australian activated carbon. The carbon filling is machine-packed for superior compaction, and the compaction maintained by a ring of Acoustafoam expanding compaction foam. The deep carbon bed is confined within concentric mesh cylinders made from rugged perforated Zintec sheet, with end caps also made of Zintec for strength. A machine-washable pre-filter sleeve is provided and secured with elastic silicon bands at either end to prevent dust clogging the filter. Even with its impressive airflow rating, this filter will capture malodorous volatiles.
Machine-packed premium Australian activated carbon
Compaction maintained by Acoustafoam ring
Rugged all-Zintec body
Washable pre-filter sleeve
RAM AirTech Heavy Filter 250mm Technical Specifications:
Rated for airflow up to: 2000 m³/hr
Duct / filter neck nominal diameter: 250 mm (10”)
Filter length: 660 mm (26”)
Carbon bed depth: 60mm
Cylindrical Zintec perforated mesh: 55% open area
Body material: Zintec zinc-coated steel sheet.
FAQs: Q: How should I choose a carbon filterto match the fan that I shall use? A: When setting up your ventilation system, of course the first consideration is the diameter. It is simpler to set up if ducting, fan and filter all have the same nominal diameter, although the diameter of fan and filter can vary. If this is the case, it is recommended to use a filter of a slightly larger diameter than the fan, rather than the other way around. Bear in mind that adding ducting and a filter will increase the operating pressure of the system, and consequently the actual flow rate of your fan will be reduced from its free flow rate. As a rule of thumb, choose a filter with a flow rate 20% larger than the fan’s free flow rate. Also, remember that all filters work more effectively if the actual air flow is lower than the rated air flow. A filter with a higher rated air flow than the true air flow of the system will work more effectively, for longer.
Activated Carbon Pellets are great for extracting organic compounds from the air.
Carbon filters incorporating activated carbon pellets are the ideal filtration system solution for hydroponic gardens. Apart from filtering air, carbon filters also trap odour molecules, mainly produced by plants such as chilli peppers, orchids, herbs & spices and thus serve a dual purpose of improving air circulation and keeping the cultivating area odour free.
After 12 to 18 months of use, the filters begin to lose their effectiveness and need to be replaced.
Sold per 1Kg
( pellets are 4 mm in diameter, 3 to 7 mm in length on average )
Carbon is activated by burning it in an oxygen-depleting atmosphere. Similar to how wood smoulders in a stove when only a small amount of oxygen is present. In a kiln it is similar, but there is much less oxygen and the temperatures are much higher. When the carbon is exposed to these high temperatures in the presence of little oxygen and with excess steam, microscopic pores open up within the carbon. This creates a greater surface area and charges the carbon with positive electrons which attracts the negatively charged ions in the organic compound (i.e. smells and gases).
ALL activated carbon is rendered ineffective in an environment with humidity levels over 85%. Keep humidity levels below 80% or the odour absorbing reaction will be unable to take place inside the carbon.
HydroDepot Dual Speed Inline Fan 200mm – a two speed mixed flow fan, perfect for high pressure, quiet air movement. They have an integral mounting bracket and come wired with a 1.5m lead. They have a release system, making it easy to maintain and clean.
RUNS AT EITHER 690M³ OR 840M³, WITH THERMAL OVERHEATING PROTECTION
Power Draw: 123 / 128 W, 0.53 Amp
Noise: 55 / 63 db
More on ventilation…
Ventilation fans like the HydroDepot Dual Speed Inline Fan 200mm fans are essential components in grow tents and grow rooms, providing a controlled environment that is crucial for the health and productivity of plants. These fans facilitate the exchange of stale, humid air with fresh air, which helps maintain optimal temperature and humidity levels. Proper ventilation prevents mold and mildew growth, reduces the risk of pest infestations, and ensures that plants receive an adequate supply of carbon dioxide, which is vital for photosynthesis. By maintaining a stable environment, ventilation fans help create the ideal conditions for robust plant growth and high yields.
Moreover, ventilation fans play a significant role in managing odors and improving overall air quality within grow tents and grow rooms. Many plants, especially those with strong fragrances, can produce odors that may be overwhelming in enclosed spaces. Ventilation systems equipped with carbon filters can effectively neutralize these odors, ensuring a pleasant working environment. Additionally, good air circulation helps prevent hot spots and ensures that all parts of the plants receive uniform exposure to light and nutrients. This even distribution promotes consistent growth patterns and helps maximize the efficiency of lighting and nutrient use, contributing to healthier, more productive plants.
The beauty of being able to chat with an LLM is how easy it is to get all the info you are looking for without having to search the web or call or email anyone anymore. BE WARNED… at present THEY SOMETIMES DO “LIE” / TALK NONSENSE (“Hallucinate“) !!! YOU NEED TO CHECK AND VERIFY WHAT YOU LEARN FROM THEM, in the same way that you would when hearing things from other people!
That being said, if you have ANY growing related questions, the AI will most certainly be able to provide clarity, explanations and guidance on these matters within SECONDS…
EXAMPLES OF THINGS ONE COULD ASK…
What size fan do I need for X or Y size grow tent, and what should the capacity of a carbon filter be when used with such a fan?
How many plants can I grow in X or Y space?
What would my lighting requirements be for an X by Y sized indoor Lettuce farm?
What should I feed my Chili plants for maximum yield?
How do I treat powdery mildew?
What’s the deal with plants and CO2?
Should I use organic or or mineral nutrients to get the most taste and smell from my Cannabis?
… the options are endless!
The AI will explain all of this (and MUCH more) to you instantly, AND … you can then ask it to explain parts of its answers in greater detail, until you fully understand the concept!
The Meaco Deluxe 202 Ultrasonic Humidifier not only keeps the air humid and clean, the humidified air you breathe in has also been sterilized by an ultraviolet lamp, prior to humidification. Running a humidifier in hard water areas can be an issue due to the build up of calcium carbonate deposits. With this in mind the Deluxe 202 comes with a large limescale filter to help soften the water before humidification.
The Meaco Deluxe 202 Ultrasonic Humidifier has a range of controls to help you get the best out of the humidifier with a three stage mist output, aroma diffuser, hot or cold mist function, auto humidistat and a variable mist output for more even distribution of the clean, humidified air within the room. The Deluxe is suitable for large rooms up to 65m².
Ultrasonic humidifier and air purifier with remote control
A Mist Level Button changes the humidification output level
Adjustable humidity level between 40% RH and 80% RH
Noise level of ≤ 35dB(A) when the setting is on Cool Mist and ≤ 45dB(A) for the Warm Mist feature
Warm and cool mist with Aroma Diffuser
Combined HEPA and Charcoal filter with up to 6 months lifespan
Best used with Soft Water
Ultraviolet (UV) lamp to clean the water before humidification
Hard water filter to prevent limescale build up
Suitable for rooms up to 65m²
Up to 17-hours run time
72 hour time-out switch – must long-press power button once every 72 hrs to reset this timer
2 year parts and labor warranty
Technical Specs:
Mist Capacity
300ml / hour in cool mist mode
400ml / hour in warm mist mode
Moisture Output (High)
≥400ml/h (Warm mist)
≥300ml/h (Cool mist)
Moisture Output (Medium)
≥300ml/h ( Warm mist)
≥200ml/h (Cool mist)
Moisture Output (Low)
≥200ml/h ( Warm mist)
≥100ml/h (Cool mist)
Tank Capacity
5.3 liters
Power
25W in cool mist mode
105W in warm mist mode
Noise Level
Maximum 35dB(A)- Cool Mist
Maximum 45dB(A)- Warm Mist
